We provide automated workflows for labs of all sizes and budgets, along with a choice selection of extraction methods based on the need. Our large volume blood workflows enable the processing of anywhere from 0.5ml up to 10ml.



Extraction Services

Is your lab experiencing limited staff, time, or budget? AutoGen provides DNA and RNA extraction services to meet the demands of any project. Our dedicated team has the expertise to extract and isolate nucleic acids from a wide variety of samples with cost-effect solutions. Learn how we can help save your lab time and effort.

Category:

Instruments

High Throughput

FlexSTAR platform workflow (FlexSTAR / FlexSTAR+) – Includes protocols for 0.5-2 ml, 2-5 ml, and 6-10 ml of fresh or frozen whole bloodFlexstar front 2
  • Throughput: Loads 1-30 samples from a variety of primary tube sizes directly on the instrument
  • Chemistry: Customizable workflow incorporating proven and reliable precipitation-based chemistry with 17 years of long-term storage data while offering automated liquid handling from primary sample tubes to final DNA storage tubes
  • Unique Features:
    • High-quality gDNA, free from protein or RNA contaminants – up to 200kb molecular weight and up to 400μg of ready-to-use DNA for your downstream and long-term storage
    • Tracks and records barcodes throughout the process to preserve sample integrity
    • FlexSTAR kits include all required consumables for nucleic acid purification and require far less plasticware than other, less environmentally friendly solutions



Medium Throughput

XTRACT 16+ – Extraction of DNA and RNA from up to 1.2ml bloodxtract 16
  • Throughput: Processes 1-16 samples
  • Chemistry: Magnetic, bead-based
  • Unique Features:
    • Easy-to-use touch screen operation
    • UV decontamination
    • LIMs integration with sample tracking/bar code scanning



Low Throughput

QuickGene-610L0004 QuickGene 610L
  • Throughput: Extracts 1-6 samples of 1-2ml whole blood in 12 minutes
  • Chemistry: Ultra-thin, polymer, membrane-based, bench-top system, that does not require centrifugation or vacuum
  • Unique Features:
    • Higher molecular weight due to gentle positive air pressure, minimizing shearing
    • Multiple input racks add to daily throughput with checkerboard processing
    • Easy to use
    • Variable resuspension volumes
QuickGene-Mini8L Non-automated version of the QuickGene-610LQuickGene Mini8L
  • Throughput: Processes 1-8 blood samples of 1-2ml (each) at once
  • Chemistry: Ultra-thin, polymer, membrane-based, bench-top system, that does not require centrifugation or vacuum
  • Unique Features:
    • Provides a faster workflow in comparison to a standard manual kit
    • Compact and affordable
